J-hook suspension clamp

J hook type suspension clamps are designed to provide a suspension for 5 to 20mm aerial ADSS cables at intermediate poles on cable routes with angle < 20° on access networks (spans up to 120m).
Online orders

4kn~10kn J hook suspension clamp for fiber cable hanging

Suface processing: Dacromet Surface processing: Suelectroplate

4kn~10kn J hook suspension clamp for fiber cable hanging

Surface processing: Hot-dip Gavanized (10kn, size is bigger than another 2 type)

Type	J hook type suspension clamp
suitable cable dia.	5-8mm, 8-12mm, 10-15mm,15-20mm optional
Material	Dacromet/Suelectroplate/Hot dip Gavanized carbon steel
application	for hanging adss fiber optic cable
Breaking load	4kn/6kn/10kn optional

Characteristic:

• Two sizes to cover the full range of ADSS cables from 5 to 20mm..
• The shape of the J Hook allows a running out of the cable directly in the hook
• The suspension clamps can be directly secured to the poles using bolts or bandings.
They can also be installed on hook bolts to provide some flexible suspension point and give extra protection to the cable against wind induced vibrations.

Application

It can be installed by bolt or stainless steel banding strap.

4kn~10kn J hook suspension clamp for fiber cable hanging
